Site-to-Site: Home Networks

This guide shows how to connect two home networks together so devices can communicate across locations—without installing NetBird on every device.

What You'll Achieve

After following this guide, devices on one home network can communicate with devices on another home network. For example:

  • Your home NAS can back up to your parents' NAS
  • Family members can access shared media servers
  • IoT devices can communicate across homes
Home A: NAS ──► Routing Peer ──► NetBird Tunnel ──► Routing Peer ──► Parents' NAS
        (no NetBird)  (peer)                           (peer)        (no NetBird)

Site-to-Site requires Network Routes because the Networks feature doesn't yet support bidirectional routing between sites.

Prerequisites

Example Scenario

  • Your home: 192.168.1.0/24 with routing peer "home-rpi"
  • Parents' home: 192.168.2.0/24 with routing peer "parents-rpi"

Step 1: Create Setup Keys with Groups

Before installing NetBird on your routing peers, create setup keys with auto-assigned groups:

  1. Go to Setup Keys in the NetBird dashboard
  2. Click Create Setup Key
  3. For your home routing peer:
    • Network Identifier: "Home Routing Peer"
    • Auto-assigned groups: Create and add home-routing-peers
    • Click Create
  4. Repeat for parents' home:
    • Network Identifier: "Parents Routing Peer"
    • Auto-assigned groups: Create and add parents-routing-peers

You can also add groups to peers manually after setup. Go to Peers, select the peer, and add groups under Assigned Groups.

Step 2: Install NetBird on Routing Peers

At your home:

curl -fsSL https://pkgs.netbird.io/install.sh | sh
sudo netbird up --setup-key YOUR_HOME_SETUP_KEY

At parents' home:

curl -fsSL https://pkgs.netbird.io/install.sh | sh
sudo netbird up --setup-key YOUR_PARENTS_SETUP_KEY

Step 3: Create Network Routes

  1. Go to Network Routes in the dashboard
  2. Click Add Route

For your home network:

  • Network range: 192.168.1.0/24
  • Routing Peer: Select "home-rpi" (or use "home-routing-peers" Peer Group)
  • Distribution Groups: "parents-routing-peers"
  • Access Control Groups: "home-routing-peers" (optional—for route-level policies, this group becomes the destination in access policies; without it, policies targeting this route won't apply)
  • Network Identifier: home-lan
  • Enable Masquerade in Additional Settings (recommended for simplicity)
  • Click Add Route

Create route for home network

For parents' home network:

  • Network range: 192.168.2.0/24
  • Routing Peer: Select "parents-rpi" (or use "parents-routing-peers" Peer Group)
  • Distribution Groups: "home-routing-peers"
  • Access Control Groups: "parents-routing-peers" (optional—for route-level policies, this group becomes the destination in access policies; without it, policies targeting this route won't apply)
  • Network Identifier: parents-lan
  • Enable Masquerade in Additional Settings (recommended)
  • Click Add Route

Create route for parents network

Step 4: Create Access Policies

Create two policies that allow the routing peers to communicate in both directions:

  1. Go to Access Control > Policies
  2. Add first policy:
    • Network Identifier: "Home to Parents"
    • Source: "home-routing-peers"
    • Destination: "parents-routing-peers"
    • Protocol: All (or restrict as needed)

Create policy for home to parents

  1. Add second policy:
    • Network Identifier: "Parents to Home"
    • Source: "parents-routing-peers"
    • Destination: "home-routing-peers"
    • Protocol: All (or restrict as needed)

Create policy for parents to home

Step 5: Configure Clientless Devices

For devices without NetBird to reach the other network, add a static route pointing to the local routing peer.

On a Linux device at your home:

# Route to parents' network through your routing peer
sudo ip route add 192.168.2.0/24 via 192.168.1.100

Where 192.168.1.100 is your routing peer's local IP.

On a Windows device:

route add 192.168.2.0 mask 255.255.255.0 192.168.1.100

For persistent routes, configure them in your router's DHCP settings or the device's network configuration.

Router-level configuration (recommended):

Configure your router to advertise routes via DHCP or add a static route that applies to all devices:

# On your home router
Destination: 192.168.2.0/24
Gateway: 192.168.1.100 (your routing peer's IP)

Step 6: Test Cross-Network Access

From a device at your home:

ping 192.168.2.1  # Parents' router
ping 192.168.2.50 # Parents' NAS

From a device at parents' home:

ping 192.168.1.1  # Your router
ping 192.168.1.50 # Your NAS

Troubleshooting

Site-to-site not working:

  1. Verify both routing peers are online and connected: check netbird status on each
  2. Check that static routes are configured on clientless devices
  3. Ensure access policies allow traffic in both directions

Can't reach specific devices:

  1. Verify the device has a route to the remote network
  2. Check firewall rules on the target device
  3. Ensure the routing peer can reach the target on its local network

Traffic works one way but not the other:

  1. Check that both network routes exist
  2. Verify access policies exist for both directions
  3. Ensure static routes are configured at both ends

Advanced Configuration

For masquerade options, ACL Groups for access control, and detailed troubleshooting, see Advanced Configuration.
